SPECIFICATIONS

Rated Output:

3.0mV/V ± 1%

Zero Balance:

± 1% of rated output

Creep after 20 minutes:

0.03% of rated output

Nonlinearity:

0.03% of rated output

Hystersis:

0.02% of rated output

Repeatability:

0.02% of rated output

Temp. effect on output:

0.002% of applied output/oC

Temp. effect on zero:

0.002% of rated output/oC

Safe Temp. Range:

-10oC to + 80oC

Temp. Compensated:

-10oC to + 50oC

Safe Overload:

1.5 x rated capacity

Input Impedance:

380Ù ± 30Ù

Output Impedance:

350Ù ± 3Ù

Insulation Resistance:

>5000 MÙ

Rated Excitation:

10V DC/AC

Maximum Excitation:

20V DC/AC

Cable Length:

20 feet
